Page 22
PSL-22
SEAM-LOC 24
®
© Metal Sales Manufacturing Corporation/ Subject to change without notice/ Effective Date 9/11
800.406.7387 (Corporate Office) • www.metalsales.us.com
seam-loC 24
®
ssr r
akewall
wiTh
r
egleT
f
lashing
d
eTail
#
1
/
4
-14 x
7
/
8
" Stitch XL (1'-0" o.c.)
SSR Rake Cleat
#12-14 x 1
1
/
2
" SD XL (1'-0" o.c.)
Double Bead Tape Sealant
#12-14 x 1
1
/
4
" Shoulder SD (1'-0" o.c.)
Floating Rake Angle
Rake Angle
Tube Sealant
Reglet Flashing
SSR Rakewall
e
xPansion
d
eTail
#
1
/
4
-14 x
7
/
8
" Stitch XL (1'-0" o.c.)
SSR Rake Cleat
#12-14 x 1
1
/
4
" SD XL (1'-0" o.c.)
Seam-Loc 24 Panel (field cut panel and bend up
to match height of rake angle for off module
application)
Double Bead Tape Sealant
#12-14 x 1
1
/
4
" Shoulder SD (1'-0" o.c.)
Floating Rake Angle
Custom Expansion Joint
Rake Angle
3
1
/
4
"
Maximum
1
/
4
:12 SLOPE
MINIMUM
1
/
4
:12 SLOPE
MINIMUM
Seam-Loc 24 Panel (field cut panel and bend up to
match height of rake angle for off module application)
