PSL-20
SEAM-LOC 24 ®
© Metal Sales Manufacturing Corporation/ Subject to change without notice/ Effective Date 9/11
800.406.7387 (Corporate Office) • www.metalsales.us.com
ssr s
CUlPTUred
r
ake
(o
ff
m
odUle
) d
eTail
1 /
4
:12 SLOPE
MINIMUM
SSR Rake Slide
Double Bead Tape Sealant
SSR Sculptured Rake (off module)
# 1 /
4
-14 x 7 /
8
" Stitch XL (1'-0" o.c.)
SSR Rake Cleat
#12-14 x 1
1 /
2
" SD XL (1'-0" o.c.)
Seam-Loc 24 Panel (bend up to match
height of Floating Rake Angle)
Double Bead Tape Sealant
#12-14 x 1 1 /
4
" Shoulder SD (1'-0" o.c.)
Floating Rake Angle
Rake Angle
# 1 /
4
-14 x 7 /
8
" Stitch XL (1'-0" o.c.)
