Introduction
1.1 About These Instructions
These Operating Instructions are provided to assist the user in connecting and
commissioning the PositionServo drive with model number ending in “EX” or “RX”. Read
this manual in its entirety and observe all safety instructions contained in this document.
All persons working on or with the controller must have the Operating Instructions
available and must observe the information and notes relevant for their work.
C A B D E F
Type:
E94P120Y2NEX
ID-No: 13014745
INPUT: 1(3)/PE
120/240 V
24.0 (13.9) A
50-60 HZ
OUTPUT: 3/PE
0 - 230 V
12.0 A
For detailed information
refer to instruction
Manual: S94P01
SN 13014745012345678
E94P120Y2NEX0XX## ##
Made in USA
Model 940
13014745012345678
A B C D E F
Certifications Type Input Ratings Output
Ratings
Hardware
Version
Software
Version
1.2 Scope of Supply
Scope of Supply Important
• 1 Model PositionServo type E94P
or E94R.
• 1 Users Manual (English)
• 1 MotionView CD ROM including:
- configuration software
- documentation (Adobe Acrobat)
After reception of the delivery, check immediately
whether the scope of supply matches the accompanying
papers. Lenze- AC Tech does not accept any liability for
deficiencies claimed subsequently.
Claim
• visible transport damage immediately to the
forwarder
• visible deficiencies / incompleteness immediately to
your Lenze representative.
1.3 Legal Regulations
Identification Nameplate CE Identification Manufacturer
Lenze controllers are
unambiguously designated
by the contents of the
nameplate In compliance with
the EC Low-Voltage
Directive AC Technology Corp.
member of the Lenze Group
630 Douglas Street
Uxbridge, MA 01569 USA
Application
as directed E94P or E94R servo controller
• must only be operated under the conditions prescribed in these Instructions.
• are components for:
- closed loop control of variable speed/torque applications with PM synchronous motors.
- installation in a machine.
- assembly with other components to form a machine.
• are electric units for installation in control cabinets or similarly enclosed housing.
• comply with the requirements of the Low-Voltage Directive.
• are not machines for the purpose of the Machinery Directive.
• are not to be used as domestic appliances, but only for industrial purposes.
Drive systems with E94P or E94R servo inverters
• comply with the EMC Directive if they are installed according to the guidelines of CE-
typical drive systems.
• can be used for:
- for operation on public and non-public mains
- for operation in industrial premises and residential areas.
• The user is responsible for the compliance of his application with the EC directives.
Any other use shall be deemed as inappropriate!
