Operation
To configure drive:
1. Ensure that the control is properly installed and mounted. Refer to section 4
for installation instructions.
2. Perform wiring to the motor and external equipment suitable for desired
operating mode and your system requirements.
3. Connect the Ethernet port P2 on the drive to your PC Ethernet port. If
connecting directly to the drive from the PC, a crossover cable is required.
4. Make sure that the drive is disabled.
5. Apply power to the drive and wait until “
diS ” shows on the display. For
anything other than this, refer to the chart below before proceeding.
Drive Display Meaning
-EP- EPM missing. Refer to 6.1.2
EPM EPM data. Refer to 6.1.2
- - - - No valid firmware
- - - -
Monitor mode
6. Confirm that the PC and the drive have the correct IP setting. Refer to
section 5.4.1.1 - Setting Your PC IP Address.
7. Launch MotionView software on your computer.
8. From the MotionView menu, select .
9. Select “Ethernet UDP”, then click the OK button.
10. From the MotionView menu, select .
11. Click the Discover button to ping the network for any drives. If a drive
is located the address will appear on the screen. If no address appears
then you can type the IP address in. The default address for the drive is
192.168.124.120. Click the Connect button to connect to the drive.
12. Once MotionView connects to the drive, its node icon will appear in the upper
left-hand corner of the Parameter Tree Window. Refer to the PositionServo
Programming Manual for more details.
Note
MotionView’s “Connection setup” properties need only be
configured the first time MotionView is operated or if the port
connection is changed. Refer to MotionView User’s Manual
for details on how to make a connection to the drive.
13. Double-click on the drive’s icon to expand parameter group’s folders.
14. Select the motor to be used according to the section 4.5.
15. Expand the folder “Parameters” and choose the operating mode for the drive.
Refer to section 5.3.1 for details on operating modes.
16. Click on the “Current limit” parameter, refer to section 5.3.3 and enter current
limit (in Amp RMS per phase) appropriate for the motor.
17. Click on the appropriate “Peak current limit” parameter, refer to section 5.3.4,
based on the “Drive PWM frequency” parameter, refer to section 5.3.2, used
and enter the peak current limit (in Amps RMS per phase) appropriate for
your motor.
18. Set up additional parameters suitable for the operating mode selected in step 17.
19. After you configure the drive, proceed to the tuning procedure if operating
in “Velocity”, or “Position” mode. “Torque” mode doesn’t require additional
tuning or calibration. Refer to section 6.6 for details on tuning.
