Mechancal installation
Bellows
4
21 BA 33.0003 EN 1.0
Note!
Please note that the recommendation of a lubricant/grease does not mean
that Lenze is liable for these lubricants or damages resulting from
incompatibilities of materials used.
4.4 Motor support
See Ch. 4.3
Stop!
When installing the motor using the intended support, ensure that the bolt
being inserted in the support is completely seated.
ƒ MDSLS056: Bolt ∅35mm
Depth of seat 6 mm
ƒ MDSLS071: Bolt ∅35mm
Depth of seat 8 mm
Alternatively, the motors can be mounted using the fixing holes in the A-end shield in the
tool/system (B14 mounting).
ƒ MDSLS056: Pitch circle ∅80 mm; M6
ƒ MDSLS071: Pitch circle ∅130 mm; M8
4.5 Bellows
To protect the spindle from dirt, it must be covered with dust-proof bellows.
Note!
The bellows selection must consider the maximum occurring surface
temperature of the motor!
