Technical data
Rated data
3
16 BA 33.0003 EN 1.0
3.2 Rated data
Note!
ƒ
The listed values apply for operation with Lenze servo inverters 9300 or ECS:
– Operation at 400-V mains
– Switching frequency 4 kHz, 8 kHz or 16 kHz.
ƒ
For operation with other servo inverters:
– Do not fall below 4-kHz switching frequency.
– Depending on the modulation and control mode of the servo inverter, the
temperature monitoring may respond. In this case, reduce power!
Rated data Motor Comment
MDSLSBS056-33 MDSLSBS071-13
Current, connection voltage,
power
See nameplate
Rated speed [min -1 ] 3000
Maximum speed [min -1 ] 3000 Higher speeds destroy the motor
Rated torque [Nm] 4.2 8.3
Maximum torque [Nm] 17.2 35.2 Excessive torques lead to spindle break
or demagnetisation
Max. axial force [kN] at 0 min -1 10 15 Excessive forces shorten the service
l f
Radial force [N] maximum ≤ 1 % F
N
life.
Weight with brake [kg] 13.5 21
Linear drive
Lift [mm] 160 170
Traversing speed [mm/s] 250
Travel tolerance [mm] 0.2
Spindle
Lead [mm] 5
Diameter [mm] 20 25
Connection (A-side) M16 x 1.5;
Thread length 60
mm
M20 x 1.5;
Thread length 60
mm
Spindle type Ball-and-screw spindle
Initial stress ---
Protection against torsion By installing the drive in the tool, i.e.
no locking element in the motor
Lubrication Grease chamber in the motor, filling
via external grease supply
Sound pressure level
Sound pressure [db (A)] < 70 Sound pressure level, A-analysed
Distance = 1 m
Motor in no-load operation,
U = 3000 min -1
Fan operation
U = 3000 min -1
Operation with servo inverter 9300
Switching frequency 4 kHz, 8 kHz or
16 kHz
