Parameter setting
6-17 BA2112EN
Signal configuration C0005 Bit 15
(AIF-CTRL.B15) Bit 14
(AIF-CTRL.B1
4) Bit 13
(AIF-CTRL.B13) Bit 12
(AIF-CTRL.B12) Bit 11
(AIF-CTRL.B7) Bit 6
(AIF-CTRL.B5) Bit 5
(AIF-CTRL.B4)
vector control 1xx3 / 2xx3 / 3xx3
/ 5xx3 / 10xx3
NSET-RFG-STOP
(RFG stop) NSET-RFG-0
(RFG zero) Reserved DCTRL-PAR*1 DCTRL-PAR-
LOAD NSET-TI*1 NSET-TI*2
vector control 4xx3 NSET-RFG-STOP
(RFG stop) NSET-RFG-0
(RFG zero) Reserved DCTRL-PAR*1 DCTRL-PAR-
LOAD NSET-JOG*1 NSET-JOG*2
vector control 6xx3 / 7xx3 / 8xx3
/ 9xx3
Reserved Reserved Reserved DCTRL-PAR*1 DCTRL-PAR-
LOAD Reserved Reserved
vector control 11xx3 Reserved Reserved Reserved Reserved Reserved Reserved Reserved
6.1.3.3 Status word
Bit Name Meaning
0 Ready to switch on Controller status information
0 = Status lower than “READY TO SWITCH ON“
1 = Status at least “SWITCHED ON“
1 Ready for operation Controller status information
0 = Status lower than “READY FOR OPERATION“
1 = Status at least “READY FOR OPERATION“
2 Operation enabled Controller status information
0 = Status lower than “OPERATION ENABLED“
1 = Status “OPERATION ENABLED“
3 Fault Controller status information
0 = No fault (TRIP))
1 = Fault (TRIP) occured
4 Voltage inhibited Information about command “Voltage inhibit“
0 = Command active
1 = Command not active
5 Quick stop Information about command “QUICK STOP“
0 = Command active
1 = Command not active
6 Switch-on inhibit Controller status information
0 = Status not “SWITCH-ON INHIBIT“
1 = Status “SWITCH-ON INHIBIT“
7 Warning Collective warning
0 = No warning
1 = warning
8 Message Collective message. Automatic setting and resetting of pulse inhibit in the controller status ”OPERATION ENABLED”. Reasons for
this can be undervoltage or overvoltage as well as overcurrent (clamp).
0 = No message
1 = Message (IMP)
9 Remote 82xx, 821x, 822x, 8200 vector: Bus access right depends on Lenze parameter ”Operating mode” (C0001)
0 = C0001 ≠ 3
1 = C0001 = 3
93XX: DOZD\V
10 Setpoint reached Status of speed/frequency deviation
0 = RFG on
≠ RFG off
1 = RFGon = RFGoff
11 Limit value Status of the DRIVECOM speed limitation
always 0
12 Reserved 820X, 821X, 822X: Reserved
8200 vector, 93XX: Mapping to bit C0150.B14
13 Reserved 820X, 821x, 822x: Reserved
8200 vector: Mapping to bit C0150.B15
93XX: Mapping to bit C0150.B3
14 Manufacturer 820X, 821x, 822x: I max (current limit reached)
0 = Current limit not reached
1 = Current limit exceeded
8200 vector, 93XX: Mapping to bit C0150.B2
15 Manufacturer 820X, 821x, 822x: Q min (f d < dQmin )
0 = Q min not active
1 = Q min active
8200 vector, 93XX: Mapping to bit C0150.B5
