EDS94AYCEN EN 9.0 - 09/2012
L
61
E94AYCEN communication manual (Ethernet)
Parameter reference
Parameters of the communication module for slot MXI2
C14002
C14003
Parameter | Name:
C14002 | Ethernet gateway address
Data type: UNSIGNED_8
Index: 10573
d
= 294D
h
The gateway address is required if the Servo Drive 9400 is not located in the same subnetwork as the PC.
• The gateway address consists of four numbers from 0 to 255 which can be set in the four subcodes.
Setting range
(min. value | unit | max. value)
0
255
Subcodes
Lenze setting
Info
C14002/1
127
Gateway address
• Sequence: "[1].[2].[3].[4]"
• Lenze setting: "127.0.0.1"
C14002/2
0
C14002/3
0
C14002/4
1
;
Read access ; Write access CINH PLC STOP No transfer
Parameter | Name:
C14003 | Ethernet: MAC-ID
Data type: UNSIGNED_8
Index: 10572
d
= 294C
h
The MAC-ID is a globally unique identifier of an Ethernet-capable device. The MAC-ID is assigned by the
manufacturer and permanently burnt into the device (Lenze communication module).
• The MAC-ID consists of six numbers from 0 to 255 which are displayed in the six subcodes.
Display range
(min. value | unit | max. value)
0
255
Subcodes
Info
C14003/1
MAC-ID
• Sequence: "[1]-[2]-[3]-[4]-[5]-[6]"
C14003/2
C14003/3
C14003/4
C14003/5
C14003/6
;
Read access Write access CINH PLC STOP No transfer
