E94AYCEN communication manual (Ethernet)
Commissioning
Configuring the communication module
6.2.3 IP address
The IP address is required for addressing the Servo Drive 9400 if communication between
the PC and the controller is to be established via an Ethernet connection.
 The IP address consists of four numbers between 0 and 255 which respectively are
separated from each other by a point, e. g. "192.168.10.1".
 Eight bits are reserved for each of the four numbers, which makes a total of 32 bits.
 The first one, two, or three numbers indicate the network (Net-ID), the remaining
numbers indicate the host (Host-ID). The definite specification of the part that is to be
evaluated as Net-ID is effected via the Subnet mask
( 31)
.
Codes
6.2.4 Subnet mask
The subnet mask indicates which part of the IP address is evaluated as net ID or host ID.
 The subnet mask consists of four numbers which are separated by a point, e.g.
"255.255.255.0".
 Eight bits are reserved for each of the four numbers, which makes a total of 32 bits.
Examples
1. The first three numbers of the IP address indicate the network, the last number
indicates the host (Lenze setting):
2. The first two numbers of the IP address indicate the network, the last two numbers
indicate the host:
3. The first number of the IP address indicates the network, the remaining three numbers
indicate the host:
Parameter (MXI1): C13000/1 C13000/2 C13000/3 C13000/4
Lenze setting 127 . 0 . 0 . 1
Parameter (MXI2): C14000/1 C14000/2 C14000/3 C14000/4
Lenze setting 127 . 0 . 0 . 1
Subnet mask: 255 . 255 . 255 . 0
Subdivision of IP address: Net ID Host ID
Subnet mask: 255 . 255 . 0 . 0
Subdivision of IP address: Net ID Host ID
Subnet mask: 255 . 0 . 0 . 0
Subdivision of IP address: Net ID Host ID
