6 Electrical installation
Wiring the CAN bus
EDK94AYCCA DE/EN/FR/ES/IT 3.0 40
l
H1_E_INST−Leitungslaenge 3−9400
Bus cable length
)
Note!
ƒ It is absolutely necessary to comply with the permissible cable lengths.
ƒ Please note the reduction of the total cable length due to the signal delay
of the repeater (
^ 42).
ƒ Mixed operation
– Mixed operation refers to different nodes which are connected to the
same network.
– If the total cable lengths of the nodes are different at the same baud
rate, the smaller value must be used to determine the max. cable
length.
1. Please check the compliance with the total cable length in Tab. 1.
The total cable length is determined by the baud rate.
Baud rate [kbit/s] Max. bus length [m]
10 8000
20 3900
50 1500
125 630
250 290
500 110
800 40
1000 17
Tab. 1 Total cable length
