Inbetriebnahme
Einstellmöglichkeiten durch DIP−Schalter
EDK94AYCCA DE/EN/FR/ES/IT 3.0
22
l
H1inbet−bevor
Einstellen der Übertragungsrate
d
c
b
a
Übertragungsrate
OFF
ON
ON
OFF
10 kBit/s
OFF
ON
OFF
ON
20 kBit/s
OFF
OFF
ON
ON
50 kBit/s
OFF
OFF
ON
OFF
125 kBit/s
OFF
OFF
OFF
ON
250 kBit/s
OFF
OFF
OFF
OFF
500 kBit/s
ON
ON
ON
OFF
800 kBit/s
OFF
ON
OFF
OFF
1000 kBit/s
OFF
ON
ON
ON
Automatische Erkennung
