Legend for fold−out page
Pos. Description Detailed
information
S205 DIP switch for setting the
l number of process data words and parameter data words
l Baud rate
^ 46
X205 Connection for voltage supply
l 2−pin plug connector with spring connection
^ 44
X206 INTERBUS connection, input (IN)
l 9−pin Sub−D connector
^ 40
X207 INTERBUS connection, output (OUT)
l 9−pin Sub−D socket
MS
LED status indicators for diagnostics ^ 51
ME
BS
BE
DE
