Elektrische Installation
INTERBUS−Anschluss
EDK94AYCIB DE/EN/FR/ES/IT 1.0
17
l
−H2−verbdg zum IBS
Belegung der 9−poligen Sub−D−Buchse X207 (OUT)
Pin
Bezeichnung
Ein−/Ausgang
Beschreibung
1
DO2
Ausgang
RS485: DO2 nicht invertiert
2
DI2
Eingang
RS485: DI2 nicht invertiert
3
GND
Bezugspotenzial
4
GND
5
Vcc5
Ausgang
5 V DC
6
/DO2
Ausgang
RS485: DO2 invertiert
7
/DI2
Eingang
RS485: DI2 invertiert
8
Vcc5
Ausgang
5 V DC
9
RBST
Melde−Eingang
Verbindung zum abgehenden INTERBUS
gesteckt.
