Electrical installation
Example circuit
4
l
38 EDK94ZPS113 DE/EN/FR/ES/IT 4.0
4.2 Example circuit
L3
N
PE
L1
L2
F1...F3
Z1
F4
K1
K1
K1
L1 L2 L3
E94ASxExxxx
X100
-UG
O
I
RFR
+UG
Rb2 Rb1
R
B
R B
U V W
X105
BD1 + BD2 -
X107
X5
T1
GI
RFR
T2
X106
M
3~
R
Y
J
J
2 7
. . .
E94AZPxxxxx
+
-
?
?
EYF...
+ -
X7
X3
+ -

A1- A1+
+
+
SSP94PSP01
Fig. 4−1 Example circuit of installation backplane and standard device
E94ASxExxxx 9400 Single Drive servo axis module
E94AZPxxxxx Installation backplane
F1 ... F4 Fuses
Z1 Mains filter/RFI filter (optional)
" HF shield termination through large−surface connection to functional
earth
EYF... System cable for resolver feedback
RFR Controller enable
K1 Mains contactor
R Resolver
RB Brake resistor
Y Motor holding brake (connected to optional motor brake control)
 Speed setpoint selection via analog input 1 (−10 ... 0 ... +10 V)
‚ Voltage source for the motor holding brake
ƒ 24−V voltage source for the digital inputs according to IEC 61131−2
