About these instructions
This documentation applies to the smd frequency inverter, and contains important technical
data including installation, operation, and commissioning instructions.
Please read the instructions in their entirety before commissioning.
A
B
C
D
E F
Made in USA
Inverter
smd
Type:
ESMD222W2SFA
Id-No: 13060481
N10104
Z519
LISTED
5D81
IND. CONT. EQ.
Input: 1/N/PE (2PE)
230/240 V
18.0 A
50-60 Hz
Output: 3/PE
0-230 V
9.5 A
2.2 kW / 3 HP
0 - 240 Hz
For detailed information
refer to instruction
Manual SW03
SN: 13060481012345678
ESMD222W2SFA000XX XX XX
1341308801234567
+
CANopen: basic I/O
Scope of delivery
Important
• 1 smd inverter (ESMD...)
with EPM installed
(see Section 4.2)
• 1 Operating Instructions
After receipt of the delivery, check immediately whether
the items delivered match the accompanying papers.
Lenze does not accept any liability for deficiencies
claimed subsequently.
Claim
• visible transport damage immediately to the
forwarder.
• visible deficiencies/incompleteness immediately to
your Lenze representative.
A Certifications
B Type
C Input Ratings
D Output Ratings
E Hardware Version
F Software Version
