Installation 3 installation, 1 mechanical installation – Lenze SMD 0-25kW-4-0kW Basic I/O User Manual
Page 10
8
Lenze 13466185 EDBSW03 v5
Installation
3
Installation
3.1
Mechanical installation
3.1.1
Dimensions and mounting
a
4 x M4
2,4 Nm
21 lb-in
c
a1
b1
b2
>50
>50
>15
>15
b
smd002
Type
a [mm]
a1 [mm]
b [mm]
b1 [mm]
b2 [mm]
c [mm]
m [kg]
ESMD251W2SFA
93
84
146
128
17
83
0.5
ESMD371W2SFA
ESMD551W2SFA
93
84
146
128
17
92
0.6
ESMD751W2SFA
ESMD152W2SFA
114
105
146
128
17
124
1.2
ESMD222W2SFA
114
105
146
128
17
140
1.4
ESMD371W2TXA
93
84
146
128
17
83
0.5
ESMD751W2TXA
93
84
146
128
17
92
0.6
ESMD112W2TXA
93
84
146
128
17
141
1.2
ESMD152W2TXA
ESMD222W2TXA
114
105
146
128
17
140
1.4
ESMD302W2TXA
114
105
146
128
17
171
1.9
ESMD402W2TXA
114
105
146
100
17
171
1.7
WARNING!
Drives must not be installed where subjected to adverse environmental conditions
such as: combustible, oily, or hazardous vapors or dust; excessive moisture; excessive
vibration or excessive temperatures. Contact Lenze for more information.
