Lenze SMD 0-25kW-4-0kW Basic I/O - Manual (Page 15)

Lenze 13466185 EDBSW03 v5 13
Commissioning
4.3 Parameter menu
Code Possible Settings
IMPORTANT
No. Name Lenze Selection
C00
Password entry 0 0 999 Visible only when password is active
(see C94)
C01
Setpoint source 0 Setpoint source: Control configuration:
0,1 Code c40 Control = terminals
Programming = keypad/limited CANopen
Monitoring = CANopen
Note: RPDOs not processed in these
modes
2 CANopen Control = terminals
Programming = CANopen / keypad
Monitoring = CANopen
Note: Only frequency setpoint part of
RPDOs are processed in this mode
3 CANopen Control = CANopen
Programming = CANopen / keypad
Monitoring = CANopen
C02
Load Lenze setting 0 No action/loading complete
• C02 = 1... 4 only possible with OFF
• C02 = 2 : C11, C15 = 60.0 Hz,
C87 = 1740 RPM, and C89 = 60 Hz
1 Load 50 Hz Lenze settings
2 Load 60 Hz Lenze settings
3 Load OEM settings
4 Translate
WARNING!
C02 = 1... 3 overwrites all settings! TRIP circuitry may be disabled! Check
codes CE1...CE3.
NOTE
If an EPM that contains compatible data from a previous software version is
installed, C02 = 4 converts the data to the current version.
