Commissioning
Code
Possible Settings
IMPORTANT
No.
Name
Lenze
Selection
CE1
Configuration -
Digital input E1
1
1 Activate fixed setpoint 1 (JOG1)
• Use C37...C39 to adjust fixed
setpoints
• Activate JOG3: Both terminals =
HIGH
2 Activate fixed setpoint 2 (JOG2)
3 DC braking (DCB)
See also C36
4 Direction of rotation
LOW = CW rotation
HIGH = CCW rotation
5 Quick stop
Controlled deceleration to standstill,
active LOW; Set decel rate in C13
6 CW rotation
7 CCW rotation
CW rotation = LOW and CCW rotation =
LOW: Quick stop; Open-circuit protected
CE2
Configuration -
Digital input E2
4
8 UP (setpoint ramp-up)
UP = LOW and DOWN = LOW: Quick
stop; Use momentary NC contacts
9 DOWN (setpoint ramp-down)
10 TRIP set
Active LOW, triggers
EEr
(motor coasts
to standstill)
NOTE:
NC thermal contact from the
motor can be used to trigger this input
11 TRIP reset
See also c70
12 No action
can be used if Ex inputs are used only
as CANopen digital inputs
CE3
Configuration -
Digital input/output
E3
3
1...12 (same as above)
13...19 (reserved)
20 Ready
21 Fault
22 Motor is running
23 Motor is running - CW rotation
24 Motor is running - CCW rotation
25 Output frequency = 0 Hz
26 Frequency setpoint reached
27 Threshold (C17) exceeded
• 1...11 configures term. E3 as an input
• 20...30 configures term. E3 as a
current-sourcing (PNP) output rated
12 VDC / 50 mA
28 Current limit reached
• in either motor or generator mode
29 No action
• Output disabled
30 CANopen Control
• output controlled by RPDO (h66,h76 = 4)
Note
A
CFG
fault will occur under the following conditions:
• E1...E3 settings are duplicated (each setting can only be used once)
• One input is set to UP and another is not set to DOWN, or vice-versa
C08
Configuration
- Relay output
(terminals K14 and
K12)
1
Relay is energized if
0 Ready
1 Fault
2 Motor is running
3 Motor is running - CW rotation
4 Motor is running - CCW rotation
5 Output frequency = 0 Hz
6 Frequency setpoint reached
7 Threshold (C17) exceeded
8 Current limit reached
in either motor or generator mode
9 CANopen Control
Output controlled by RPDO (h66,h76 = 4)
