15 Leica RM2125 RTS
• Open the packaging.
• Take out all accessories (1) and the Instruc-
tions for Use.
• Remove the Allen key No. 8 and lay it off to
the side.
• Remove the cardboard tray (2).
• Remove all foam material.
• Remove the carton bridge (3).
• Use both carrying straps (4) at the front and
rear to remove the instrument on the wooden
pallet from the carton.
Do not transport the instrument by
holding it by the handwheel grip,
coarse feed wheel, or rotary knob for
setting the section thickness!
• Set the wooden pallet with the instrument on
a stable table.
• Slightly lift the wooden pallet in front from
below.
• Loosen the safety screw (6) with washer
under the wooden pallet using the provided
Allen key No. 8 (7).
• Cut open and remove the protective sleeve
(5).
• To lift the instrument, grasp the front and
rear of the baseplate and lift it from the
wooden pallet.
• Place the instrument on a stable laboratory
table. The two sliding elements (8) located
on the rear of the base plate make it easier
to move the instrument on the table.
• To move the instrument, hold it by the front
of the base plate, lift it up gently and slide it
on the sliding elements.
4. Startup
4.3 Unpacking and installation
Fig. 7
1
3
2
4
5
7
6
8
