Landoll XL144/XLC144/XLD144/XLH144/XLO144 X-Fold Pulverizer User Manual
Page 35
LED Wiring Layout and Components
Tie Strap
Tie Strap
Locknut,
1/4-20
Screw,
1/4-20 X 1-1/2
Tail Light
Mount
Red
LED
U-Bolt,
5/8-11
Screw,
1/4-20 X 1-1/2
Amber
LED
Locknut,
1/4-20
Lamp Bracket
Locknut,
1/2-13
U-Bolt,
1/2-13
Locknut,
5/8-11
LED
Wiring
Harness
Module
Bracket
Light
Module
7 Pin
Harness
U-Bolt,
3/8-16
Locknut,
3/8-16
182rev0713 Page 19C 5J801
XL-PulvElectLayout
