Landoll SSP6 SURE STAND GRASS SEEDER - Manual (Page 17)

3-1
Chapter 3
Operation
Seeder Operation
This chapter covers the basic operation and usage
procedures for the Landoll Brillion Sure Stand Seeder.
Be sure to read and understand the Safety Procedures
and Cautions starting on page 1-2.

WARNING
Figure 3-1: Parking Pin
Parking Pin
When hooking up the seeders:
1. Attach the tractor.
2. Remove the Klik pin, pull the parking pin into outer
position, replace the Klik pin. See Figure 3-1.
When unhooking the seeders:
1. Remove the Klik pin, push in the parking pin, replace
the Klik pin. See Figure 3-1.
2. Disconnect the tractor.
To prevent the implement from tipping backward
on the frame, disengage the parking pin only
when the seeder is fully attached to the tractor.
Be sure to observe the following sequences.
PARKING PIN
KLIK PIN
(USE THIS HOLE WHEN
DISCONNECTED FROM TRACTOR)
(USE THIS HOLE WHEN CONNECTED
TO TRACTOR)
