2-2 7K555
ASSEMBLY OF OPTIONAL EQUIPMENT
Figure 2-2: Agitators
Lift Sling Kit (Optional)
1. If not already assembled to the machine, attach a
mounting bracket to each side of machine at the
center holes of the right and left end plates. (A strap
may need to be added to one side to equalize the
thickness of plates on the both sides of the machine.)
2. Attach the lift sling to mounting brackets with 5/8” x
11/2” capscrews and stover nuts provided in kit. See
Figure 2-3.
3. Slide stabilizer into frame tube and secure with clevis
pin and hairpin cotter.

CAUTION
Shaft out
right end
Check
Shaft
Rotation
Direction
Brush
Agitator
Assembly
Cage
Agitator
Lockwasher, 5/16”
Nut, 5/16-18
Intermediate
Bearing
Cotter Pin
5/32 x 1 1/2”
End
Bearing
w/ bushing
Washer
Washer
Capscrew,
5/16-18 x 1 1/4”
FRONT OF
MACHINE
Stay clear of machine when using the lift sling to
lift or move it. Do not work under machine using
only the sling to support it. Keep observers away.
