5-2
1K965
GENERAL REFERENCE AND SPECIFICATIONS
Table 5-2: Pulvi-Mulcher Specifications - ML Series 18’ 9”(Continued)
CL - Crowfoot front wheels, notched rear wheels
CC - Crowfoot front and rear wheels
LC - Notched front wheels, crowfoot rear wheels
MLS-2253
MCLS-2253
MLCS-2253
MCCS-2253
Approximate Weight
7,035 lbs. (3,166 kg)
6,972 lbs. (3,137 kg)
6,822 lbs. (3,070 kg)
6,758 lbs. (3,041 kg)
Working Width
18 ft. 9 in. (5.63 m)
18 ft. 9 in. (5.63 m)
18 ft. 9 in. (5.63 m)
18 ft. 9 in. (5.63 m)
Transport Width
19 ft. 6 in. (5.85 m)
19 ft. 6 in. (5.85 m)
19 ft. 6 in. (5.85 m)
19 ft. 6 in. (5.85 m)
Transport Height
3 ft. 8 in. (1.1 m)
3 ft. 8 in. (1.1 m)
3 ft. 8 in. (1.1 m)
3 ft. 8 in. (1.1 m)
Overall Length Transport
19 ft. 10 in. (5.95 m)
19 ft. 10 in. (5.95 m)
19 ft. 10 in. (5.95 m)
19 ft. 10 in. (5.95 m)
Pulverizer Wheels Front
20 in. (500 mm)
Notched Ductile Iron
20 in. (500 mm)
Notched Ductile Iron
20 in. (500 mm)
Notched Ductile Iron
20 in. (500 mm)
Notched Ductile Iron
Number of Wheels
54
36
54
36
Pulverizer Wheels Rear
20 in. (500 mm)
Notched Ductile Iron
20 in. (500 mm)
Notched Ductile Iron
20 in. (500 mm)
Crowfoot Ductile Iron
20 in. (500 mm)
Crowfoot Ductile Iron
Number of Wheels
55
55
37
37
Rear Roller Scrapers
Standard
Standard
NA
NA
Roller Axle Size
4 in. (102 mm)
4 in. (102 mm)
4 in. (102 mm)
4 in. (102 mm)
Type of Teeth
12 mm "S-Tine" Teeth with
2.75 in. (70 mm) Points
12 mm "S-Tine" Teeth with
2.75 in. (70 mm) Points
12 mm "S-Tine" Teeth with
2.75 in. (70 mm) Points
12 mm "S-Tine" Teeth with
2.75 in. (70 mm) Points
Number of Teeth
35
35
35
35
Nominal Teeth Spacing
6 in. (153 mm)
6 in. (153 mm)
6 in. (153 mm)
6 in. (153 mm)
Tooth Depth Control
Independent Depth Control
Cylinders
Independent Depth
Control Cylinders
Independent Depth Control
Cylinders
Independent Depth Control
Cylinders
Maximum Tooth
Depth of Operation
6 in. (153 mm)
6 in. (153 mm)
6 in. (153 mm)
6 in. (153 mm)
Hitch
Pull-Type w/Hydraulic Lift
Pull-Type w/Hydraulic Lift
Pull-Type w/Hydraulic Lift
Pull-Type w/Hydraulic Lift
Tire Size
9.5 L x 15-6 Ply
Implement Rib (Duals)
9.5 L x 15-6 Ply
Implement Rib (Duals)
9.5 L x 15-6 Ply
Implement Rib (Duals)
9.5 L x 15-6 Ply
Implement Rib (Duals)
Road Clearance
9 in. (229 mm)
9 in. (229 mm)
9 in. (229 mm)
9 in. (229 mm)
Safety Warning Lights &
SMV Emblem
Standard
Standard
Standard
Standard
Rear Hitch
Optional
Optional
Optional
Optional
Land Leveler Kit
Optional
Optional
Optional
Optional
Front Roller Scraper Kit
(Notched Rollers)
Optional
NA
Optional
NA
V-Leveler Kit
Optional
Optional
Optional
Optional
Safety Chain Kit
Standard
Standard
Standard
Standard
Independent Hydraulic
Tooth Control
Standard
Standard
Standard
Standard
Horsepower
Requirements
6 to 8 HP (4.5 to 6 kW) per
ft.
6 to 8 HP (4.5 to 6 kW) per
ft.
6 to 8 HP (4.5 to 6 kW) per
ft.
6 to 8 HP (4.5 to 6 kW) per
ft.
Recommended
Operating Speed
3 to 6 MPH (5 to 10 km/h)
3 to 6 MPH (5 to 10 km/h)
3 to 6 MPH (5 to 10 km/h)
3 to 6 MPH (5 to 10 km/h)
