TONEcube & PROBEplus
Instruction Manual
TONEcube FEATURES
The Klein Tools TONEcube is a professional series tone generator for wire
tracing. It features several tone frequencies and strong power output to
assist in tracing wire.
• Five different tone sounds selectable by tone switch.
• Constant output level over useful battery life.
• Tone auto-off after 1.5 hours.
• No battery drain in continuity mode with leads open.
• Separate status LEDs for normal and reverse line polarity.
• Tone operates in either continuity or status modes.
• Modular plug for direct connection to phone jacks.
• Alligator clips for wire connection.
• Sliding momentary tone switch prevents accidental activation.
• Battery low indication.
• Lanyard attachment loop.
TONEcube GENERAL SpEcIFIcATIONS
• Dimensions: 2.75" x 2.5" x 1.42" (6.99 x 6.35 x 3.61 cm)
• Weight: 7.0 oz. (200 grams) with battery
• Operating Temperature: 0°C to 50°C / 32°F to 122°F
• Storage Temperature: -20°C to 60°C / -4°F to 140°F
• Humidity: 10% to 90%, non-condensing
• Altitude: 10,000 feet (3,000 meters) maximum
• Battery Life : 9V alkaline battery - typical
• Standby: 4 years
• Active: 120 hours
• Tone Sounds: high-warble, low-warble, mono, ascending, descending
• continuity Indication: less than 10k Ω
• Voltage protection:
• Status Mode: 60 Volts
• continiuity Mode: 20 Volts through external 600 Ω
• Tone power : 8dBm (into 600 Ω until battery low)
pROBEplus FEATURES
The Klein Tools PROBEplus is a professional series tone tracer for wire
tracing and cable identification. It features digital volume control and a loud
built-in speaker to assist you in tracing and identifying wire.
• Tap power button to toggle on/off: continuously holding down the
power button is optional.
• Hold on/off button to power on; release to power off.
• Digital volume control.
• Tone detection LED.
• Amplifier overload LED.
• Battery Low Indication.
• External tip replacement.
• Lanyard attachment loop.
pROBEplus GENERAL SpEcIFIcATIONS
• Dimensions: 9.85" x 2.00" x 1.14" (25.02 x 5.08 x 2.90 cm)
• Weight: 6.0 oz. (170 grams) with battery
• Operating Temperature: 0°C to 50°C / 32°F to 122°F
• Storage Temperature: -20°C to 60°C / -4°F to 140°F
• Humidity: 10% to 90%, non-condensing
• Altitude: 10,000 feet (3,000 meters) maximum
• Battery Life : 9V alkaline battery - typical
• Standby: 4 years
• Active: 25 hours
WARNINGS
To ensure safe operation and service of the instruments, follow these
instructions. Failure to observe these warnings can result in severe injury
or death.
• The TONEcube and PROBEplus are designed for use on extra low
voltage cabling systems (less than 60 volts).
• The maximum voltage across the test leads of the TONEcube is 60
volts in status (STAT) mode and 20 volts in the continuity (CONT)
mode. Connecting the TONEcube to live mains AC power may
damage it and pose a safety hazard for the user.
• These instruments are not designed to be used outdoors.
• Do not use instruments if they are wet, as this could pose a shock
hazard.
• Turn off instruments before attempting to replace batteries, and
disconnect all test leads from the TONEcube.
• Do not use instruments if they are damaged in any way.
WARNINGS:
Always wear approved eye protection.
Do NOT use on energized circuits.
