Kinze 3600 Lift and Rotate Planter Rev. 6/14 User Manual
Page 9
ITEM
PART NO.
QTY.
DESCRIPTION
1
G10014
G10228
4
4
Hex Head Cap Screw, ½"-13 x 1", 12 Row 36"/38"
Lock Washer, ½", 16 Row 30"
2
GD9959
GD5154
2
4-6
Wear Pad, Nylatron, 4" x 4"
Shim, 4" x 4"
3
G10894
-
External Washer
4
GD3537-17
1
Shaft, 1¼" x 6⅜", 12 Row 36"/38"
5
GA7423
G10641
1
-
Tongue Hook W/Grease Fittings, 12 Row
Grease Fitting, ⅛" NPT
6
GD5804
G10468
1
2
Pin, 1¼" x 12", 12 Row
Cotter Pin, ⅜" x 2"
7
GD8188
GD8189
-
-
Hose Clamp, ⅞" x 3" x 5⅜"
Rubber Strip, ⅜"
8
---
-
9
G11169
G10111
1
1
Hex Head Cap Screw, ½"-13 x 3½"
Lock Nut, ½"-13
10
G10004
G10229
G10101
1
1
1
Hex Head Cap Screw, ⅜"-16 x 1¼"
Lock Washer, ⅜"
Hex Nut, ⅜"-16
11
GD10650
1
Hose Clamp
12
G10003
G11387
G10108
1
1
1
Hex Head Cap Screw, ⅜"-16 x 1½"
Flat Washer, ⅜" SAE
Lock Nut, ⅜"-16
13
GD10664
1
Shield (If Applicable)
14
GD5173
G10462
1
1
Pin, 1¼" x 5⅛"
Cotter Pin, 3∕16" x 2"
15
G10131
1
Square Head Set Screw, 5∕16"-18 x ¾"
16
GB0246
1
Shoe
17
GD3537-11
1
Shaft, 1¼" x 7", 12 Row
18
A7428
-
Inner Hitch, 191⅝", 12 Row 36"/38"
(Non-Stock Item)
19
---
-
See “Tongue Cylinder, 12 Row 30” with “T” Hitch and 12 Row 36”/38” with “Y” Hitch”
on page 26
20
---
-
See “Tongue Lock Cylinder”
(Located in M0236-02)
21
GD10530
G10229
G11091
1
2
2
U-Bolt, 2⅛" x 1⅞" x ⅜"-16
Lock Washer, ⅜"
Serrated Flange Nut, ⅜"-16
22
G10585
G11389
G10071
1
1
1
Hex Head Cap Screw, ½"-13 x 3¼"
Flat Washer, ½" Plated SAE
Serrated Flange Nut, ½"-13
23
GD10538-01
1
Sleeve
24
GD13543
GD13544
GD13545
GD13546
1
1
1
1
Shim, 2½" x 10", 7 Gauge
Shim, 2½" x 10", 10 Gauge
Shim, 2½" x 10", 12 Gauge
Shim, 2½" x 10", 14 Gauge
25
GD18116
1
Shield (If Applicable)
26
GD5875
G10108
1
1
Hose Clamp, 9∕16" x 2½" x 2"
Lock Nut, ⅜"-16
27
GD8189
GD8188
G10111
1
1
1
Rubber Strip, ⅜"
Hose Clamp, ⅞" x 3" x 5⅜"
Lock Nut, ½"-13
28
G6400-06-08
GR1037
2
-
Connector W/O-Ring, 9⁄16"-18 Male JIC To ¾"-16 O-Ring
O-Ring
Inner Hitch, “Y”
Model 3600
M0242
Rev. 8/12
P6
