ITEM PART NO. QTY.
(Per Assy.)
DESCRIPTION
1 GA7116 - Arm, Second Stage, 138 ¼", 12 Row 36"/38"
GA7118 - Arm, Second Stage, 172 ¼", 16 Row 30"
2 GD1701
G10460 1
2 Pin, 1¼" x 6½"
Cotter Pin, ¼" x 2"
3 G10979
G10159
G10322 4
-
-
Special Washer, 1¼" (As Required)
Machine Bushing, 1¼", 10 Gauge (As Required)
Machine Bushing, 1¼", 18 Gauge (As Required)
4 GA11768
G10640
G10463 -
-
- Pin W/Grease Fitting, 1¼" x 13"
Grease Fitting, ¼"-28
Cotter Pin, ¼" x 1½"
5 GA13759 - Arm, First Stage
6 GA8170
G10536 1
-
Safety Lockup W/Detent Pins, 19⅜"
Detent Pin, ½" x 2 ½" Grip
7 G10012
G10068
G10006
GD7805
G11391
G10230
G10104 -
-
-
8
-
8
8
Hex Head Cap Screw, ⅝"-11 x 6½" (If Applicable)
Hex Head Cap Screw, ⅝"-11 x 6" (If Applicable)
Hex Head Cap Screw, ⅝"-11 x 2¼" (If Applicable)
Special Washer, ⅝", Hardened
Flat Washer, ⅝" SAE
Lock Washer, ⅝"
Hex Nut, ⅝"-11
8 GD0453-09
GD0453-03 1
-
Extension Tube, 75", 12 Row 36"/38" and 16 Row 30" (L.H. Even-Row Marker) (If Applicable)
Extension Tube, 50", 12 Row 36"/38" and 16 Row 30"
9 --- - See “Row Marker (Cushion) Cylinder, All Sizes” on page 28
10 GD0652
G10460 1
2 Pin, 1¼" x 9½"
Cotter Pin, ¼" x 2"
11 GA11769
G10640
G10463 -
-
- Pin W/Grease Fitting, 1¼" x 11½"
Grease Fitting, ¼"-28
Cotter Pin, ¼" x 1½"
12 GD10793
GD11791 -
- Shim, 2½" x 12½", 16 Gauge (As Required) (Shown)
Shim, 2½" x 8¼", 16 Gauge (As Required)
13 GA4877 1 Mount
14 GA13721 1 Stand, 30"
15 GD2721
G10228
G10102 3
6
6 U-Bolt, 2" x 2" x ½"-13
Lock Washer, ½"
Hex Nut, ½"-13
16 GD9981 1 Bar
17 GD4743
G11389
G10228
G10102 2
4
4
4 U-Bolt, 3" x 3" x ½"-13
Flat Washer, ½" Plated SAE
Lock Washer, ½"
Hex Nut, ½"-13
18 G10017
G11389
G10111 2
2
2 Hex Head Cap Screw, ½"-13 x 1½"
Flat Washer, ½" Plated SAE
Lock Nut, ½"-13
19 GA9088 - Molded Stop, 12¼" Long
20 G10979 4 Special Washer, 1¼" (As Required)
21 GD13359 2 Plate, 7" x 7"
22 G11396
G10322 2
2 Flat Washer, 1¼" SAE
Machine Bushing, 1¼", 18 Gauge
Row Marker Assembly, 12 Row 36"/38" and 16 Row 30"
Model 3600 M0242
7/11 P22
