Kinze 3600 Lift and Rotate Planter Rev. 6/14 - Manual (Page 15)

Center Frame
ITEM PART NO. QTY. DESCRIPTION
1 G10102
G10828 1
1 Hex Nut, ½"-13
Hex Socket Set Screw, ½"-13 x 1¼"
2 G10404
G10234
G10336 -
-
- Machine Bushing, 3⅛" x 2⅛" x 3∕16" (As Required)
Machine Bushing, 2⅛", 10 Gauge (As Required)
Machine Bushing, 2⅛", 14 Gauge (As Required)
3 GD10531 1 Hinge Pin, 2⅛" x 25¾"
4 GD10492 2 Adjustment Block
5 G10085
G11392
G10112 -
-
- Hex Head Cap Screw, ¾"-10 x 3¾"
Flat Washer, ¾" SAE
Lock Nut, ¾"-10
6 GA7390 - Safety Hook
7 GD9898 1 Pin, 1¼" x 215∕16"
8 G11391
G10107 2
2 Flat Washer, ⅝" SAE
Lock Nut, ⅝"-11
9 GD10006 2 Spring
10 GD9870 1 Pin, 1¼" x 6"
11 GA6943 2 Spring Rod
12 G10037
G11389
G10228
GD7904-02 2
2
2
2 Hex Head Cap Screw, ½"-13 x 1¼"
Flat Washer, ½" Plated SAE
Lock Washer, ½"
Sleeve, ½" x ½" Long
13 GA7579
GD10706
GD10707
G10001 4
-
-
-
Pad Holder W/Bars
Bar, 1¼" x 6" x ¼" Thick
Bar, 1¼" x 6" x ⅜" Thick
Hex Head Cap Screw, ⅜"-16 x 1"
14 GD25374 8 Wear Pad
15 GD7805
G10104 4
4 Special Washer, ⅝", Hardened
Hex Nut, ⅝"-11
16 GD9968 1 Cap
17 GD8188
GD8189 1
1 Hose Clamp, ⅞" x 3" x 5 ⅜"
Rubber Pad
18 G10053
G10228
G10102 1
1
1 Hex Head Cap Screw, ½"-13 x 2½"
Lock Washer, ½"
Hex Nut, ½"-13
19 G10543
G10105 16
16 Hex Head Cap Screw, ¾"-10 x 3", Full Thread
Hex Nut, ¾"-10
20 --- - See “Valve Blocks - Located On R.H. Rear Center Frame” (Located in M0236-02)
21 A7393
GA6929
GA6928 -
-
- Frame W/Cam Follower Mounts, 136" (Non-Stock Item)
Cam Follower Mount, L.H.
Cam Follower Mount, R.H.
22 G10026 2 Hex Head Cap Screw, ¾"-10 x 2"
23 GB0409 2 Spring Washer
24 GD10532 2 Sleeve
25 GA6497
G10640 2
-
Cam Follower W/Grease Fitting
Grease Fitting, ¼"-28
Model 3600 M0242
Rev. 8/12 P12
