Kinze 3600 Lift and Rotate Planter Rev. 6/14 - Manual (Page 35)

ITEM PART NO. QTY. DESCRIPTION
1 GD4086 4 ISO Coupler
2 *A1444
*A1491
*A1447 2
2
2 Hose Assembly, ½" x 250", 12 Row 30" “T” Hitch
Hose Assembly, ½" x 246", 12 Row 36"/38" “Y” Hitch
Hose Assembly, ½" x 300", 16 Row 30" “T” Hitch
3 *A1032
*A3183
*A3184 2
2
2 Hose Assembly, ⅜" x 240", 12 Row 30" “T” Hitch
Hose Assembly, ⅜" x 246", 12 Row 36"/38" “Y” Hitch
Hose Assembly, ⅜" x 300", 16 Row 30" “T” Hitch
4 *A3216 1 Hose Assembly, ⅜" x 96", 12 Row 36"/38" “Y” Hitch, 12 Row 30" “T” Hitch
5 G6400-08
GR1037 1
-
Connector W/O-Ring, ¾"-16 Male JIC To O-Ring
O-Ring
6 *A1183
*A1119 2
2 Hose Assembly, ¼" x 157", 12 Row 30" “T” Hitch and 12 Row 36"/38" “Y” Hitch
Hose Assembly, ¼" x 216", 16 Row 30" “T” Hitch
7 G6801-06-08
GR1037 4
-
Elbow W/O-Ring, 90°, 9∕16"-18 Male JIC To ¾"-16 O-Ring
O-Ring
8 G6502-06 1 Swivel Elbow, 45°, 9∕16"-18 Male JIC To Female
9 G6400-06-08
GR1037 2
-
Connector W/O-Ring, 9∕16"-18 Male JIC To ¾"-16 O-Ring
O-Ring
10 *A1139 2 Hose Assembly, ¼" x 40", 12 Row 30" “T” Hitch, 12 Row 36"/38" “Y” Hitch And 16
Row 30" “T” Hitch
11 *A1464
*A1467
*A1462 2
2
2 Hose Assembly, ½" x 72", 12 Row 30" “T” Hitch
Hose Assembly, ½" x 120", 12 Row 36"/38" “Y” Hitch
Hose Assembly, ½" x 78", 16 Row 30" “T” Hitch
12 *A3129
*A1011
*A3113 2
2
2 Hose Assembly, ⅜" x 79", 12 Row 30" “T” Hitch
Hose Assembly, ⅜" x 125", 12 Row 36"/38" “Y” Hitch
Hose Assembly, ⅜" x 84", 16 Row 30" “T” Hitch
13 G2700-10 2 Bulkhead Tube Union, ⅞"-14 Male JIC
14 G2700-08 2 Bulkhead Tube Union, ¾"-16 Male JIC
15 *A1114
*A1106
*A1102 2
2
2 Hose Assembly, ¼" x 85", 12 Row 30" “T” Hitch
Hose Assembly, ¼" x 130", 12 Row 36"/38" “Y” Hitch
Hose Assembly, ¼" x 95", 16 Row 30" “T” Hitch
16 *A3129
*A3156
*A3159 2
2
2 Hose Assembly, ⅜" x 79", 12 Row 30" “T” Hitch
Hose Assembly, ⅜" x 68", 12 Row 36"/38" “Y” Hitch
Hose Assembly, ⅜" x 97", 16 Row 30" “T” Hitch
* Hydraulic hose is not stocked by Kinze Repair Parts, but can be made available on a special order basis. Call for quote.
Hydraulic Hoses and Fittings on Hitch
Model 3600 M0242
7/11 P32
TM
