Kinze 3600 Lift and Rotate Planter Rev. 6/14 - Manual (Page 33)

ITEM PART NO. QTY. DESCRIPTION
1 GD9977
G6801-08
GR1037
G6400-08
GR1037
G6400-10
GR1466 1
1
-
2
-
1
-
Block
Elbow W/O-Ring, 90°, ¾"-16 Male JIC To O-Ring
O-Ring
Connector W/O-Ring, ¾"-16 Male JIC To O-Ring
O-Ring
Connector W/O-Ring, ⅞"-14 Male JIC To O-Ring
O-Ring
2 GA3584
G10232
G10583 1
3
4 Ground Clamp
Lock Washer, 5∕16"
Hex Head Cap Screw, 5∕16"-18 x 2¾"
3 GA4293 2 Check Valve
4 G6801-08-10
GR1466 2
-
Elbow W/O-Ring, 90°, ¾"-16 Male JIC To ⅞"-14 O-Ring
O-Ring
5 G6408-H06-O
GR1045 6
-
Hex Socket Head Plug W/O-Ring, 9∕16"-18 O-Ring
O-Ring
6 G6801-L-08
GR1037 1
-
Long Elbow W/O-Ring, 90°, ¾"-16 Male JIC To O-Ring
O-Ring
7 GA13741
G11066
GD8066-02
GA9097
GR1635
G11067 1
2
1
1
-
2
Terminal Strip Mount
Phillips Pan Head Machine Screw, No. 10-24 x ¾", Stainless Steel
Sleeve, 1" Long
Terminal Strip W/Screws, No. 6, 14 Terminal
Screw, No. 6-32 x ¼"
Phillips Pan Head Machine Screw, No. 8-32 x ¾", Stainless Steel
8 GD9533
G6400-08-10
GR1466
G6408-10
GR1466
G6400-08
GR1037 1
2
-
2
-
7
-
Block
Connector W/O-Ring, ¾"-16 Male JIC To ⅞"-14 O-Ring
O-Ring
Plug W/O-Ring, ⅞"-14 O-Ring
O-Ring
Plug W/O-Ring, ¾"-16 O-Ring
O-Ring
9 GA3413 2 Flow Control Valve
10 --- 5 See “Solenoid Valve” on page 30 (Located in M0236-02)
11 G6801-08
GR1037 1
-
Elbow W/O-Ring, 90°, ¾"-16 Male JIC To O-Ring
O-Ring
12 G6500-08 1 Swivel Elbow, 90°, ¾"-16 Male JIC To Female
13 G6408-H06-O
GR1045 5
-
Hex Socket Head Plug W/O-Ring, 9∕16"-18 O-Ring
O-Ring
14 G6408-08
GR1037 4
-
Plug W/O-Ring, ¾"-16 O-Ring
O-Ring
15 GD13146
G10977
G10232
G10133 1
2
1
1 Valve Block Cover
Phillips Pan Head Machine Screw, No. 10-24 x ½", Stainless Steel
Lock Washer, 5∕16"
Hex Head Cap Screw, 5∕16"-18 x 1½"
16 GD13348
G10002
G11091 1
1
1 Insulated Clamp, 11∕16"
Hex Head Cap Screw, ⅜"-16 x ¾"
Serrated Flange Nut, ⅜"-16
17 GD14528
G6400-08
GR1037
G6403-NWO-08 2
2
-
2
Valve Block
Connector W/O-Ring, ¾"-16 Male JIC To O-Ring
O-Ring
Adjustable Union, ¾"-16 O-Ring
A GR0764 - Seal Kit, Includes: (2) O-Rings, (1) BU Ring
Valve Blocks - Located on R.H. Rear Center Frame
TM
M0242 Model 3600
P30 Rev. 11/11
