Outer hitch – Kinze 3600 Lift and Rotate Planter Rev. 6/14 User Manual
Page 7
Outer Hitch
ITEM
PART NO.
QTY.
DESCRIPTION
13
GA7016
1
Catch Bar
14
GD5857
1
Spring
15
GA7433
1
Transport Latch
16
G10765
-
Spring Pin, ¼" x 1"
17
G10062
GD2971-09
G10108
1
1
1
Hex Head Cap Screw, ⅜"-16 x 3"
Sleeve, 2" Long
Lock Nut, ⅜"-16
18
G11389
G10111
1
1
Flat Washer, ½" Plated SAE
Lock Nut, ½"-13
19
GD7137
G10457
1
2
Pin, ¾" x 3 ⅜"
Cotter Pin, 5∕32" x 1 ½"
20
GD8188
GD8189
-
-
Hose Clamp, ⅞" x 3" x 5⅜"
Rubber Strip, ⅜"
21
GD5875
2
Hose Clamp, 9∕16" x 2½" x 2"
22
GD9953
G11391
G10230
G10104
3
1
6
6
U-Bolt, 3" x 4" x ⅝"-11
Flat Washer, ⅝" SAE
Lock Washer, ⅝"
Hex Nut, ⅝"-11
23
---
-
24
GA4418
GA4842
GD6556
1
-
1
Roller W/Bronze Bushings, 12 Row “Y” Hitch
Roller W/Bronze Bushings, 12 Row “T” Hitch And 16 Row “T” Hitch
Bronze Bushing
25
G10108
1
Lock Nut, ⅜"-16
26
G10111
1
Lock Nut, ½"-13
27
G10026
G10112
1
1
Hex Head Cap Screw, ¾"-10 x 2"
Lock Nut, ¾"-10
28
GA5842
GD8189
1
-
Bracket, Jack Mount
Rubber Strip, ⅜"
29
GA13768
GA4845
GD2558
GD2557
1
-
-
-
Safety Pin, 12¾", 12 Row 30", 12 Row 36"/38" (“Y” Hitch Only)
Safety Pin, 14¾", 16 Row 30"
Lynch Pin, ¼"
Lynch Pin, 7∕16"
30
G10016
G11389
4
4
Hex Head Cap Screw, ½"-13 x 2"
Flat Washer, ½" Plated SAE
31
G10017
G10016
G10071
8
10
8-10
Hex Head Cap Screw, ½"-13 x 1½", 12 Row
Hex Head Cap Screw, ½"-13 x 2", 16 Row
Serrated Flange Nut, ½"-13
32
GA7029
GA7084
GA7085
GA7083
2
-
-
-
Wear Mount, 12 Row 30", 12 Row 36"/38" (“Y” Hitch Only)
Wear Mount, L.H., 16 Row 30"
Wear Mount, R.H., 16 Row 30"
Wear Pad Retainer, 16 Row 30"
33
GD5154
GD3501
-
-
Shim, 4" x 4" (As Required), All Sizes
Shim, 4" x 6" (As Required), 16 Row 30"
34
GD9959
GD9960
-
-
Wear Pad, Nylatron, 4" x 4" (As Required), All Sizes
Wear Pad, Nylatron, 4" x 6" (As Required), 16 Row 30"
35
GD7519
GD7518
3
1
Shim, 16 Gauge (16 Row Only)
Shim, ⅜" (16 Row Only)
36
G10014
G10228
G11389
4
4
4
Hex Head Cap Screw, ½"-13 x 1"
Lock Washer, ½"
Flat Washer, ½" Plated SAE
37
A7061
A7044
A7073
-
-
-
Outer Hitch, “T”, 121", 12 Row 30"
(Non-Stock Item)
Outer Hitch, “Y”, 121", 12 Row 36"/38"
(Non-Stock Item)
Outer Hitch, “T”, 151½", 16 Row 30"
(Non-Stock Item)
38
GD7251
GD5804
G10468
1
-
2
Pin, 1¼" x 14", 12 Row “T” Hitch And 16 Row “T” Hitch
Pin, 1¼" x 12", 12 Row “Y” Hitch
Pin, ⅜" x 2"
39
GA11528
1
Bracket
40
GD16642
G10228
G10102
2
4
4
U-Bolt, 3" x 4" x ½"-13
Lock Washer, ½"
Hex Nut, ½"-13
41
GB0292
-
Hitch Clevis, Single (2" Hole)
Model 3600
M0242
7/11
P4
TM
