Kinze 3600 Lift and Rotate Planter Rev. 6/14 - Manual (Page 23)

ITEM PART NO. QTY.
(Per Assy.)
DESCRIPTION
1 GA4353
G10641 1
-
Arm W/Grease Fittings, Second Stage, 110", 12 Row 30"
Grease Fitting, ⅛" NPT
2 G11396
G10159
G10322 -
-
- Flat Washer, 1¼" SAE (As Required)
Machine Bushing, 1¼", 10 Gauge (As Required)
Machine Bushing, 1¼", 18 Gauge (As Required)
3 GA11766
G10640
G10463 -
-
- Pin W/Grease Fitting, 1¼" x 1113∕16"
Grease Fitting, ¼"-28
Cotter Pin, ¼" x 1½"
4 GA11590 - Arm, First Stage
5 GD0752-41 4 Sleeve, 1"
6 GA8170
G10536 1
-
Safety Lockup W/Detent Pins, 19 ⅜"
Detent Pin, ½" x 2½" Grip
7 G10011
G10046
G10008
G11391
G10230
G10104 4
-
-
-
4
4
Hex Head Cap Screw, ⅝"-11 x 5½" (If Applicable)
Hex Head Cap Screw, ⅝"-11 x 5" (If Applicable)
Hex Head Cap Screw, ⅝"-11 x 2" (If Applicable)
Flat Washer, ⅝" SAE
Lock Washer, ⅝"
Hex Nut, ⅝"-11
8 GD0453-07
GD0453-04 1
-
Extension Tube, 45", 12 Row 30"
Extension Tube, 60", 12 Row 30" (L.H. Even-Row Marker) (If Applicable)
9 --- - See “Row Marker (Cushion) Cylinder, All Sizes” on page 28
10 GD2161
G10460 2
4 Pin, 1¼" x 8¼"
Cotter Pin, ¼" x 2"
11 GA11767
G10640
G10463 -
-
- Pin W/Grease Fitting, 1¼" x 9½"
Grease Fitting, ¼"-28
Cotter Pin, ¼" x 1½"
12 GD10792 - Shim, 2½" x 7¼", 16 Gauge (As Required)
13 GA5130 1 Mount
14 GA7042 1 Stand, 20" (12 Row 30")
15 GD2721
G10228
G10102 3
6
6 U-Bolt, 2" x 2" x ½"-13
Lock Washer, ½"
Hex Nut, ½"-13
16 GD9981 1 Bar
17 GD4743
G11389
G10228
G10102 2
4
4
4 U-Bolt, 3" x 3" x ½"-13
Flat Washer, ½" Plated SAE
Lock Washer, ½"
Hex Nut, ½"-13
18 G10017
G11389
G10111 2
2
2 Hex Head Cap Screw, ½"-13 x 1½"
Flat Washer, ½" Plated SAE
Lock Nut, ½"-13
19 GA9088 - Molded Stop, 12¼" Long
20 GD13360 2 Plate, 6" x 6"
Row Marker Assembly, 12 Row 30"
Model 3600 M0242
7/11 P20
TM
