INFICON RSH-600 Rotary Sensor User Manual
Page 31
4 - 3
IPN
1
5
3800
-G
RSH-600 Operating Manual
Figure 4-2 Rotary Sensor Head - Angled
Stainless Steel Cover
Copper Cover (not shown)
Crystal Holder
P/N 153716
P/N 153713
P/N 153731-2
Spring Retainer
Assembly
P/N 153714
Crystal Retainer
Assembly
P/N 153204-2
Retainer Screw
P/N 153715
M3x12 Screw
P/N 144-224
Spring Contact
P/N 153726
Retainer Spacer
P/N 153717
