Sensistor ISH2000 Technical Reference Manual (TRM)
Debug Mode
Do not enter this mode. Debug mode is for the manufacturer's use only. Enter-
ing debug mode will set the detector to continuously dump debugging data on
the printer port.
IMPORTANT! Setting the detector in debug mode will inhibit normal use
of the printer port.
If you have accidentally entered the debug mode, you can exit by choosing the
"Debug Mode" menu option again.
Debug Mode get to Debug Mode: Choose Menu / Service Settings / Debug
Mode/Enter the code: SEN
Print Port output:
• Time (ms) counted from power up
• Raw Sensor Signal (mV)
• Numeric value of the Detection Mode signal
• Analysis Value
All values are presented with three digits and tabs between. Printer rate: 50 Hz
(20 ms).
C 580
