Probe Control Port Connector
The control port connector is a 25-pin female D-sub.
Pin Type Signal name
1 - GND
2 - GND
3 - GND
4 In In_0
5 In In_1
6 In In_2
7 In In_3
8 In In_4
9 Out CAL_CONF
10 Out OUT_6
11 - GND
12 - GND
13 - GND
14 OUT DET_ERROR
15 OUT LEAK_OUT
16 OUT DET_ON
17 OUT DET_SIGNAL
18 OUT DET_WAIT
19 OUT OUT_0
20 OUT OUT_1
21 OUT OUT_2
22 OUT OUT_3
23 OUT OUT_4
24 OUT OUT_5
25 OUT 24 VDC OUT
