EN- 69 Sensistor ISH2000 Technical Reference Manual (TRM)
In Service Mode, the following information accessible:
In APC I/O, the following information accessible:
ADC Raw Sensor Signal (mV)
Detect Numeric value of the Detection Mode sig-
nal
Analys Analysis Value
Battery Battery voltage if portable model, (V)
Signal Sensor signal when the probe expose
Diode Temperature voltage from probe (mV)
Row Executing APC program row
Time Executing time for the row
ADC mV Raw Sensor Signal (mV)
Det Numeric value of the Detection Mode sig-
nal
Ana Analysis Value
Inputs
0 Status of external input 0
(IN_0)
1 Status of external input 1
(IN_1)
2 Status of external input 2
(IN_2)
3 Status of external input 3
(IN_3)
4 Status of external input 4
(IN_4)
Outputs
0 Status of external output
0 (OUT_0)
1 Status of external output
1 (OUT_1)
2 Status of external output
2 (OUT_2)
3 Status of external output
3 (OUT_3)
