26
3 RS-232 interface
In
te
rface D
e
scr
ipti
o
n
Ecotec E300
0,
k
ins
22e1
-j
, 1401
3.2.3 Error Messages
The following error messages may be received from the Ecotec E3000:
3.3 Interfaces settings at the Ecotec E3000
At “Settings > Interfaces” you make the settings for the interfaces.
3.3.1 Control location
 Local
 RS-232
 Local and RS-232
Local: In this mode the RS-232 interface can only be used to read data, but not for control
purposes.
RS-232: In this mode the Ecotec E3000 is controlled solely via the interface and the display
can only be used for viewing data. Even with the control location set to RS-232 some
parameter may still be able to be changed through the main units software menus. Please
lock these by the menu PIN to prevent unintended changes.
Local and RS-232: In this mode the Ecotec E3000 can be controlled via the interface but
also by input from the main display.
Default setting: Local and RS-232
3.3.2 RS-232 Protocol
The RS-232 protocol can be set to “ASCII”, “Diagnostics”, “Printer auto” or “Printer manual”.
ASCII The ASCII protocol is a protocol similar to the SCPI, a standard protocol widely used for
measuring equipment.
Table 12: Error messages
Error
number Error message Statement
OK ERR_OK Command ausgeführt
E01 ERR_CMD_START wrong command start (no "*")
E02 ERR_BLANK illegal blank
E03 ERR_CMD_WORD_1 Command Word 1 illegal
E04 ERR_CMD_WORD_2 Command Word 2 illegal
E05 ERR_CMD_WORD_3 Command Word 3 illegal
E06 ERR_DISABLED control via RS232 not enabled
E07 ERR_ARGUMENT argument wrong
E08 ERR_NO_DATA no data available
E09 ERR_OVERFLOW buffer overflow
E10 ERR_INVALID Command currently invalid
E11 ERR_NO_QUERY no query allowed
E12 ERR_QUERY only query allowed
E13 ERR_NOT_IMPLEMENTED not yet implemented
