3 RS-232 interface

25

In

te

rface D

e

scr

ipti

o

n

Ecotec E300

0,

k

ins

22e1

-j

, 1401

[:WARNing]

State warning flags

Byte 1 – Capillary

Byte 2 – CalRequest

Byte 3 – TlCommunication

Byte 4 – SnCommunication

Byte 5 – ServiceMessage

Byte 6 – Service Filter

Byte 7 – Voltages

Byte 8 – TlExpired

Byte 9 – Factor K1

Byte 10 – Flow changed

Byte 11 – TlNearlyExpired

Byte 12 – TlNew

Byte 13 – LightBarrier

R

[:ZERO]

zero (on / off)

R

*USER

:1

:2

:3

:4

:5

:6

Gas number

:NAME

Name (example: R236fa; max. 6 characters)

R/S

:MASS

Mass position [amu]

R/S

:NORMfac

Normalization factor

R/S

:MOLmass

Molecule mass (example: 102.0)

R/S

*ZERO

ZERO (update or enabling)

S

[:OFF]

ZERO off (ZERO)

S

Table 11: List of commands, ASCII (cont.)

Command

word1

Command

word2

Command

word3

Statement

Read/Set
