3 RS-232 interface

In

te

rface D

e

scr

ipti

o

n

Ecotec E300

0,

k

ins

22e1

-j

, 1401

[:SNkey]

State Sniffer key

Byte 1 left

Byte 2 right

R

[:LEAK]

ECO-Check test leak

R

[:Gas]

gas type (e.g. R134a)

R

[:GAIN]

compensation gain

R

[:LREff]

effective leak rate in [g/a]

R

[:LRNom]

nominal leak rate in [g/a]

R

[:Offset]

compensation offset

R

[Unit]

Leak rate unit

[:PROGram]

[:POInt]

I•Guide: current measuring point (number, not
measured yet, 0-end)

R

[:CYCle]

State I•Guide cycle

MOVE - “Move to point x”

WAIT - “Please wait”

CHECK - “Leak check point x”

END - Display result of cycle

CONFIRM - “Confirm point x”

(UNKNOWN - intermediate state)

R

[:GLOBal]

Global leak rate exceeded

R

[:SINGle]

Single leak rate exceeded

R

[:PROof]

status of proof function (status number)

2 - WAIT UNTIL STABLE

7 - WAIT UNTIL AIR STABLE

10 - SHOW RESULTS

16 - MEASURE LEAK

17 - REMOVE UNTIL AIR STABLE

R

[:SEARch]

[:SEARch 1]

[:SEARch 2]

[:SEARch 3]

[:SEARch 4]

Search level of gas x exceeded

DISABLED, OFF, ON

(without number “ON” is read if any gas exceeds the
search level)

R

[:SELect]

Pointer to currently highest leak rate

R

[:Gas]

Gas no. (gas displayed on the probe display)

R

[:LR]

Leak rate (in selected unit)

R

[:NAME]

Gas name

R

[:TRIGger]

Gas no. of gas exceeding trigger

0 - if no gas exceeds the trigger

R

[:SERviceHist 1]

[:SERviceHist 2]

[:SERviceHist 12]

Service history starting from 1 to 12

Date, time, operating hours, Type of maintenance,
CUSTOMER/SERVICE

R

[:TRIGger]

[:TRIGger 1]

[:TRIGger 4]

Trigger level of gas x exceeded

DISABLED, OFF, ON

(without number “ON” is read if any gas exceeds the
trigger level)

R

Table 11: List of commands, ASCII (cont.)

Command

word1

Command

word2

Command

word3

Statement

Read/Set
