3 RS-232 interface

23

In

te

rface D

e

scr

ipti

o

n

Ecotec E300

0,

k

ins

22e1

-j

, 1401

[:CAL]

status calibration (status number)

2 - LEAKRATE STABLE, CONFIRM

4- BASELINE

7 - AIR STABLE, CONFIRM

9 - PEAKFIND ARGON

10 - CAL FINISHED, CONFIRM

14 - PEAKFIND M84

15 - PEAKFIND M69

16 - MEASURE M69 /83

17 - REMOVE SNIFFER

R

[:CALHist 1]

[:CALHist 1]

[:CALHist 12]

Calibration history part1 starting from 1 to 12

Date, time, cal.-type (internal/external gas nr.), mass
position, calibration factor)

R

[:CALHist2 1]

[:CALHist2 1]

[:CALHist2 12]

Calibration history part 2 starting from 1 to 12

Operating hours, filament, flow, argon current, argon
position

R

[:CALHist3 1]

[:CALHist3 2]

[:CALHist3 12]

Calibration history part 3 starting from 1 to 12

factor, position 1, position 2, gas number/mass

R

[:CALHist 4 1

[:CALHist4 2]

[:CALHist4 12]

Calibration history part 4

starting from 1 to 12

leak rate test leak, Unit test leak,

current test leak, current background

[:CALMode]

type of calibration

(NO, PROOF, INTERNAL, EXTERNAL)

R

[:ERRor]

Current error number

(NO ERROR / WARNING, ERROR , WARNING
)

R

[:ERRorHist 1]

[:ERRorHist 2]

[:ERRorHist 12]

Error history

starting from 1 to 12

Date, Time, Error number

R

[:INput]

State PLC input

Byte 1 Pin 7

Sleep

Byte 2 Pin 20

Zero

Byte 3 Pin 9

Gas a

Byte 4 Pin 25

Gas select

Byte 5 Pin 13

Gas b

Byte 6 Pin 8

Purge

R

[:OUTput]

State PLC output

Byte 1 Pin 16

Trigger

Byte 2 Pin 4

Ready (V1)

Byte 3 Pin 17

Error

Byte 4 Pin 5

reserve (V2)

Byte 5 Pin 24/12/11 Ready (Relais)

Byte 6 Pin 10/23/22 Trigger (Relais)

R

Table 11: List of commands, ASCII (cont.)

Command

word1

Command

word2

Command

word3

Statement

Read/Set
