22
3 RS-232 interface
In
te
rface D
e
scr
ipti
o
n
Ecotec E300
0,
k
ins
22e1
-j
, 1401
:NAME name (max. 6 characters) R/S
:NR

:NRA
gas number (1 … 4) R/S
:NRB Gas number B (1 … 4) R/S
:POInts Number of points (0, 1, … 20) R/S
:TRIGger

:TRIGA
Global trigger A [in selected unit]

(unit read only, determined by gas number)
R/S
:TRIGB

:TRIGgerB
Global trigger gas B [selected unit]

(unit read only, determined by gas number B)
R/S
:WAITtime Wait time [s] (1.0, 1.1, … 25.0) R/S
:ABORT Restarting testing cycle S
:BACK Point back S
:BUTTon use of I•Guide button (right probe button) (ON, OFF) R/S
:CONFirm Confirm point S
:CYCLE Cycle counter (for resetting set counter to 0) R/S
*READ Leak rate

(first selected gas) [selected unit]
R
[1]

[2]

[3]

[4]
Leak rate gas 1

Leak rate gas 2

Leak rate gas 3

Leak rate gas 4

without gas number the first selected gas is given
[g/a]

[oz/yr]

[ppm]

[mbar*l/s]

[Pa*m3/s]

[atm*cc/s]

[Torr*l/s]
Leak rate in [g/a]

Leak rate in [oz/yr]

Leak rate in [ppm]

Leak rate in [mbar*l/s]

Leak rate in [Pa*m3/s]

Leak rate in [atm*cc/s]

Leak rate in [Torr*l/s]

(without unit the selected unit is used)
R
*SLEEP stop, go to SLEEP S
*STANDby StandBy mode (no display) S
*START start measurement mode (after SLEEP or STANDBY) S
*STATus status of the Ecotec E3000

INIT (initialisation), ACCL (acceleration), MEAS
(measuring), CALEXT (calibration external), CALINT
(calibration internal), PROOF, ERROR, SLEEP, PURGE,
STANDBY
R
Table 11: List of commands, ASCII (cont.)
Command

word1
Command

word2
Command

word3
Statement Read/Set
