52
6 Operation
Tr
an
sl
ation
o
f the
o
rig
in
al
operatin
g
in
str
u
ct
io
ns
Ecot
ec E3
000,
k
in
a
22en
1
-r
, 1
407
Test leak temperature °C / °F
Status of light barrier
Page 5: Sniffer line information
Type SL3000 / system
Software version x.x
Length 3 m / 5 m / 10 m / 15 m
Serial no. 9000 XXX XXXX
Key left
Key right
Background light Green/red Background light
Bar graph
Flow (calibration) sccm
Page 6: I/O port data
Recorder A V
Recorder B V
Sleep Low / High
Zero Low / High
Gas a/b/select Low / Low / Low
High / High / High
Input reserved Low / High
Leak/Ready/Error Low / Low / Low
High / High / High
Relay “Leak“ Low / High
Relay “Leak“ Low / High
Output reserved Low / High
Page 7: Analog data
AIN3 sniffer length V
AIN4 +5V II leak V
AIN5 +24V III ext. V
AIN6 +5V I sniffer V
AIN8 -15V MC50 V
AIN9 +15V MC50 V
AIN10 +24V MC50 V
AIN11 +24V I TSP V
AIN12 +24V II TMP V
Page 8: Analog data (2)
AIN0 V
AIN0 offset V
Foreline pressure mbar
AIN1 V
Flow sccm
AIN2 V
Table 7: Device information (cont.)
Menu item Format Description
