8 settings, 1 menu structure diagram, Settings – INFICON T-Guard Leak Detection Sensor User Manual
Page 56: Menu structure diagram
54
Operation
jina
85
e 5
.fm
Tech
ni
ca
l Ha
nd
bo
ok
(1
11
2)
7
The name of the current parameter set is displayed in the top line of the leak rate
screen. If the parameter set is being changed later, a star will be written before the
name of the parameter set.
Notice
Only insert or disconnect the I•Stick when the device is switched off. If the
I•Stick is connected or disconnected during operation, the devices cannot
recognize it.
Notice
With the first use, the I•Stick is initialized. Switch the T-Guard off and on
again to be able to use the I•Stick
5.8
Settings
All Settings referring the configuration of the T-Guard™ Leak Detection Sensor are
provided in the menu structure.
5.8.1
Menu Structure Diagram
Starting in the Main Menu, all menu screens are arranged like a tree structure.
Please find the menu structure of the T-Guard™ Leak Detection Sensor on the
following page.
In this diagram, all operations are listed.
Please find the descriptions of the individual menu items on the following pages.
Fig. 6-1 Main Menu
