Specification:
Product:
The tape is based on polyvinyl
chloride (PVC) and/or its
copolymers and has a rubber–
based, pressure–sensitive adhesive.
The tape shall be 7 mils thick, and
be UL Listed and marked per UL
Standard 510 as “Flame Retardant,
Cold and Weather Resistant.” The
tape must be applicable at
temperatures ranging from 0
° F
through 100 ° F (–18 ° C through
38 ° C) without loss of physical
properties. The tape shall be
classified for use in both indoor and
outdoor environments. The tape
shall be compatible with synthetic
cable insulations, jackets and
splicing compounds. The tape will
remain stable and will not telescope
more than 0.1 inches when
maintained at temperatures below
120
°
F (50
°
C).
Engineering/Architec
tural Specification:
Primary electrical insulation
(branch wiring in wet or dry
locations): All splices for 600 volt
wire rated 105
°
C (220
°
F) and
below shall be insulated with a
minimum of two half–lapped
layers of Scotch Super 33+ Vinyl
Electrical Tape. All connectors
having irregular surfaces shall be
padded with Scotchfil

Electrical
Insulation Putty or Scotch 130C
Rubber Splicing Tape prior to
insulating with Scotch Super 33+
Vinyl Electrical Tape.
Mechanical protection (outer
jacketing): All rubber and
thermoplastic insulating high
voltage power cable tape splices
and repairs shall be overwrapped
with at least two half–lapped
layers of Scotch Super 33+ Vinyl
Electrical Tape
Installation
Techniques:
The tape shall be applied in half–
lapped layers with sufficient
tension to produce a uniform
wind (for most applications this
tension will reduce the tape’s
width to approximately 5/8 of its
original width). On pigtail
splices, the tape shall be wrapped
beyond the end of the wires and
then folded back, leaving a
protective cushion to resist cut–
through. Wrap tape up–hill,
taping from a smaller diameter
surface to a larger diameter
surface. Apply the tape with no
tension on the last wrap to
prevent flagging.
Shelf Life:
Scotch Super 33+ Vinyl Electrical
Tape complies with the requirements
of UL 510 for storage. When
maintained under normal storage
conditions the tape will remain stable
and has a five year shelf–life.
Availability:
Scotch Super 33+ Vinyl Electrical
Tape is available from your local
3M authorized distributor in the
following standard roll sizes:
3/4 in. x 66 ft.
3/4 in. x 44 ft.
3/4 in. x 20 ft.
Other lengths and widths are
available by special request.
Scotch and Scotchfil are trademarks of 3M.
Important Notice
All statements, technical information and recommendations related to
the Seller’s products are based on information believed to be reliable,
but the accuracy or completeness thereof is not guaranteed. Before
utilizing the product, the user should determine the suitability of the
product for its intended use. The user assumes all risks and liability
whatsoever in connection with such use.
Any statements or recommendations of the Seller which are not
contained in the Seller’s current publications shall have no force or
effect unless contained in an agreement signed by an authorized
officer of the Seller. The statements contained herein are made in lieu
of all warranties, expressed or implied, including but not limited to the
implied warranties of merchantability and fitness for a particular
purpose which warranties are hereby expressly disclaimed.
SELLER SHALL NOT BE LIABLE TO THE USER OR ANY OTHER
PERSON UNDER ANY LEGAL THEORY, INCLUDING BUT NOT
LIMITED TO NEGLIGENCE OR STRICT LIABILITY, FOR ANY
INJURY OR FOR ANY DIRECT, INDIRECT, SPECIAL, INCIDENTAL
OR CONSEQUENTIAL DAMAGES SUSTAINED OR INCURRED BY
REASON OF THE USE OF ANY OF THE SELLER’S PRODUCTS
THAT WERE DEFECTIVE.
Electrical Products Division
6801 River Place Blvd.
Austin, TX 78726-9000
800 245 3573
http://www.3m.com/elpd
© 3M 1998
78-8124-4841-9(A)
