TDS LOCTITE
®
290™, January
-
2010
Chemical/Solvent Resistance
Aged under conditions indicated and tested @ 22 °C.
% of initial strength
Environment
°C
100 h
500 h
1000 h
5000 h
Motor oil (MIL-L-46152)
125
85
85
50
50
Leaded Petrol
22
90
90
90
90
Brake fluid
22
90
90
85
85
Water/glycol 50/50
87
90
90
90
90
Acetone
22
85
85
85
85
Ethanol
22
80
80
80
80
GENERAL INFORMATION
This product is not recommended for use in pure oxygen
and/or oxygen rich systems and should not be selected as
a sealant for chlorine or other strong oxidizing materials
For safe handling information on this product, consult the
Material Safety Data Sheet (MSDS).
Where aqueous washing systems are used to clean the
surfaces before bonding, it is important to check for
compatibility of the washing solution with the adhesive. In
some cases these aqueous washes can affect the cure and
performance of the adhesive.
This product is not normally recommended for use on plastics
(particularly thermoplastic materials where stress cracking of
the plastic could result). Users are recommended to confirm
compatibility of the product with such substrates.
Directions for use:
For Pre-assembled Threaded Parts with Thru Holes
1. Prior to assembly, clean all threads (bolt and hole) with a
LOCTITE
®
cleaning solvent and allow to dry.
2. For Thru Holes, apply several drops of product at screw
and body juncture.
3. Avoid touching the bottle tip to the metal surface.
For Assembly
1. For Blind Holes, apply several drops of the product
down the internal threads to the bottom of the hole
For Porosity Sealing
1. Clean area and apply localized heat to the area to
approximately 121°C.
2. Allow to cool to approximately 85°C and apply the
product.
For Disassembly
1. Remove with standard hand tools.
2. In rare instances where hand tools do not work because
of excessive engagement length, apply localized heat to
nut or bolt to approximately 250 °C. Disassemble while
hot.
For Cleanup
1. Cured product can be removed with a combination of
soaking
in a
LOCTITE
®
solvent
and
mechanical
abrasion such as a wire brush.
Loctite Material Specification
LMS
LMS dated September
-
01, 1995. Test reports for each batch
are available for the indicated properties. LMS test reports
include selected QC test parameters considered appropriate to
specifications for customer use. Additionally, comprehensive
controls are in place to assure product quality and
consistency. Special customer specification requirements may
be coordinated through Henkel Quality.
Storage
Store product in the unopened container in a dry location.
Storage information may be indicated on the product container
labeling.
Optimal Storage: 8 °C to 21 °C. Storage below 8 °C or
greater than 28 °C can adversely affect product properties.
Material removed from containers may be contaminated during
use. Do not return product to the original container. Henkel
Corporation cannot assume responsibility for product which
has been contaminated or stored under conditions other than
those previously indicated. If additional information is required,
please contact your local Technical Service Center or
Customer Service Representative.
Conversions
(°C x 1.8) + 32 = °F
kV/mm x 25.4 = V/mil
mm / 25.4 = inches
µm / 25.4 = mil
N x 0.225 = lb
N/mm x 5.71 = lb/in
N/mm² x 145 = psi
MPa x 145 = psi
N·m x 8.851 = lb·in
N·m x 0.738 = lb·ft
N·mm x 0.142 = oz·in
mPa·s = cP
Note
The data contained herein are furnished for information only
and are believed to be reliable. We cannot assume
responsibility for the results obtained by others over whose
methods we have no control. It is the user's responsibility to
determine suitability for the user's purpose of any production
methods mentioned herein and to adopt such precautions as
may be advisable for the protection of property and of persons
against any hazards that may be involved in the handling and
use thereof. In light of the foregoing, Henkel Corporation
specifically disclaims all warranties expressed or implied,
including warranties of merchantability or fitness for a
particular purpose, arising from sale or use of Henkel
Corporation’s products. Henkel Corporation specifically
disclaims any liability for consequential or incidental
damages of any kind, including lost profits. The discussion
herein of various processes or compositions is not to be
interpreted as representation that they are free from
domination of patents owned by others or as a license under
any Henkel Corporation patents that may cover such
processes or compositions. We recommend that each
prospective user test his proposed application before repetitive
use, using this data as a guide. This product may be covered
by one or more United States or foreign patents or patent
applications.
