Description
set vacuum
maximum speed
(100% = ”HI”)
switching on pressure for VACUULAN or
two point control
delay
(00:00 = Off)
switch off pressure (”Maximum” for ”Vac control”,
”Minimum” for ”Pump down”)
process runtime
time in program step y (0.....9)
pressure in program step y (0.....9)
software version
Response
XXXX mbar or
XXXX Torr or
XXXX hPa
XXX%
XXXX mbar or
XXXX Torr or
XXXX hPa
XX:XX h:m
XXXX mbar or
XXXX Torr or
XXXX hPa
XX:XX h:m
XX:XX:XX h:m:s
XXXX mbar
X
X
X
CVC 3000 VX.XX
Operation Command
IN_SP_1
IN_SP_2
IN_SP_3
IN_SP_4
IN_SP_5
IN_SP_6
IN_SP_P1y
IN_SP_P2y
IN_SP_P3y
IN_SP_P4y
IN_SP_P5y
IN_VER
time
pressure
valve
Step
Auto
Read commands
0: no venting valve in program step y (0.....9)
1: venting valve in program step y (0.....9)
0: no ”Step” in program step y (0.....9)
1: ”Step” in program step y (0.....9)
0: no ”Auto” in program step y (0.....9)
1: ”Auto” in program step y (0.....9)
