1
5
2
7
4
3
6
Rear side controller
ROTAVAC vario Pumping unit
8
jacks for connection of
VACUU•BUS components (e.g.,
coolant valve) external venting
valve)
connection plug of the
VACUU • BUS line to VARIO pump
rating plate vacuum connection
venting connection
serial interface
RS 232 C
