If the vehicle has a full size spare, unscrew the spare tire retaining wing nut and
remove tire (see FIG. 1).
FIG. 1
Unscrew the jack and remove from the vehicle (see FIG. 2).
Remove the Spare Tire Support Base, use a 1/2" socket to remove bolts
securing it to the trunk floor.
The steps are similar for the space saver spare - remove from the vehicle
Pull up at each end of the seat base to release the retainers & remove the rear
seat base (see
FIG. 3 ).
3 of 9
Vehicle Preparation
Tools Needed for Installation
• Drill
• Ratchet wrench
• 7/16" Socket
• 1/2" Socket
• 17mm Deep Well Socket
• 19mm Socket
• 7/16" Wrench • 9/32" Drill Bit
• Large Flathead Screwdriver
• Knife
• Pliers
• Permanent Marker
Ratchet Wrench
1/2" Socket
FIG. 2
FIG. 3
FIG. 4
At the bottom of the seat back use a 19mm socket to remove two nuts
(see FIG. 4).
Ratchet Wrench
19mm Socket
Tools Required
