Parts Lists
7160-0336 Upper Trunk Shelf - Dodge Charger 2011+
36"
1
1
1
1
1
2
1
1
13351
13340
13341
14377
14378
14379
14380
14381
14382
EDGE TRIM
RH DRAWER SLIDE
LH DRAWER SLIDE
LH SIDE MTG BRACKET
RH SIDE MTG BRACKET
UPPER TRAY
VERTICAL BRACKET
LH SLIDE STOP
RH SLIDE STOP
QTY PART NO. DESCRIPTION
7120-0541 Hardware Bag - Upper Trunk Shelf
4
4
16
16
13349-0001
13350-0001
1173-1412
1503-1400
NYLOK NUT M10-1.5
WASHER FLAT M10 STEEL ZINC PLT
HEX HD MS .25-20UNC x .75 LG
NYLOK NUT .25-20UNC
QTY PART NO. DESCRIPTION
1 7120-0541 HARDWARE BAG - UPPER TRUNK TRAY
7160-0020 Dodge Charger Lower Trunk Shelf
1
2
1
1
1
13336
13339
13342
7120-0385
7130-0069
LOWER TRAY
SLIDE MTG BRACKET
SLIDE MTG BRACKET
HARDWARE BAG - LOWER TRUNK TRAY
RH SLIDE ASSEMBLY w/ STUDS
QTY PART NO. DESCRIPTION
1 7130-0070 LH SLIDE ASSEMBLY w/STUDS
7120-0385 Hardware Bag - Lower Trunk Shelf
4
1
2
2
32"
1
1
4
6
12079-0005
13238-0001
13349-0002
13350-0002
13351
13352-0001
13353
13354
1173-1412
WASHER .25 EXT TOOTH
WASHER .44 FLAT
NYLOK NUT M12-1.75
WASHER M12 FLAT
EDGE TRIM
CARRIAGE BOLT .44-14 x 8.5"
WING NUT .44-14
VINYL CAP BLACK
.25-20UNC x .75 HEX HD SCREW
QTY PART NO. DESCRIPTION
4 1403-1400 .25-20UNC HEX NUT
6 1503-1400 NYLOK NUT .25-20UNC
2 11043-0001 .25 SELF-DRILLING SCREW
