System Manual Safety System CES-A-W5H-01
1
Actuator CES-A-BPA
Cube-shaped design 40 x 40 mm
Dimension drawing CES-A-BPA
Technical Data
Parameter
Value
Unit
min. typ. max.
Housing material PPS
Dimensions 40 x 40 x 10 mm
Weight 0,05 kg
Ambient temperature -5 - +70 °C
Degree of protection IP67/IP69K
Installation position Active face opposite read head
Power supply Inductive via read head
Ordering table
Series Comment Version Order no. / item
CES-A-BPA safety screws M4 x 14 are supplied -
098775
CES-A-BPA

30
±0,1
40 - 0,25
0
CES-A-BPA-098775
IP67 CD
10
4
Ø
5,2
Active face
safety screws M4 x 14
are supplied
Active face
