Technical Data
Note
If a product data sheet is included with the product, the information on the data
sheet applies in case of discrepancies with the operating instructions.
Safety switch CES-A-W5...
Read head and evaluation unit integrated in the standard housing
Semiconductor output
M1 plug connector
Dimension drawing
Switching characteristics
safety outputs
(semiconductor outputs)
1 door monitoring output
(semiconductor output,
not a safety output)
Typical operating distance
See page and page 4.





Approvals Approvals
+LA LA
+LB LB
+UB OUT
+LA LA
+LB LB
+UB OU T
Safety guard
closed (actuator detected) open (actuator not in the operat-
ing distance)
Read
head
Actuator
Read
head
30
M12x1
±0,1
±0,1
13
11
8
45,5
40
5,3
60
7,3
( 131 )
16,5
40,5
30
40
LED gn
LED rd/ye
Active face
